TATA SK 712
Ab Profit Hoga Aur Bhi Zyaada
SFC Wide Cabin
Gear Shift Advisor
Fleetedge Telematics
Firmware Over The Air
Why Choose TATA SK 712?
Ab Profit Hoga Aur Bhi Zyaada
Low CRR Tyre
Gear Shift Advisor
3 Years Warranty
Light & Havy Mode
| Models | TATA SK 712 TT BS6PH2 |
|---|---|
| Engine | 4SPCR BSVI Ph2 |
| Engine Type | 4 Cylinder in line water cooled direct Injection diesel engine with intercooler |
| Engine Displacement | 2956 cc |
| Power | 74.5 kW (100 Ps) Light Mode | 92 kW Heavy Mode (125 Ps) @ 2 800 г/min |
| Torque | 300 Nm @ 1000 - 2 200 г/min (Light Mode) | 360 Nm @ 1400 - 1800 г/min (Heavy Mode) |
| Clutch | Single plate dry friction type - 280 mm dia (with Booster) |
| Gearbox | G550, 5 Speed, MK2 Manual Synchromesh Gearbox (5F, 1R) |
| Gearbox Ratio | 1st - 8.07,2nd - 4.76, 3rd - 2.75, 4th - 1.66, 5th - 1.00, Rev - 7.48 |
| Suspension - Front Type | Parabolic leaf spring with Hydraulic nos Double acting Telescopic Shock Absorbers |
| Suspension - Rear Type | Semi Elliptical leaf spring, with 2nos Double Acting Shock Absorbers with Additional Auxiliary Springs |
| Tyres | 7.50R16 - 16PR Low CRR Tyre (Front - 2 / Rear - 4) Spare - 1 |
| Cabin Type | Semi Forward Day Cabin - 1900 mm |
| Steering Type* | Power Steering (4 Spoke) |
| Brakes Type | Dual Circuit Full Air S" Cam Brakes With Auto Slack Adjuster (Drum - Drum) - 325 mm |
| Ground Clearance | 213 mm |
| Gradeability | 33 % |
| Rear Axle | Banjo Type - Single reduction htpoid gears, fully floating axle shafts - RAR: 4.85 |
| Battery | 12V, 100 Ah |
| Fuel Tank Capacity | 90 L HD Polimer Fuel Tank |
| Load Body Variants | CAB & HSD |
| GVW | 7 490 kg |
| FAW | 3 640 kg |
| RAW | 3 850 kg |
| Long member Size (LxBxH) | 200 mm x 60 mm x 5 mm |
| Wheel Base | 3 405 mm |
| TCD | 10 400 mml |
| Variants | CAB, HSD |
| Load Body Dimenssions CuM | NA, 4 Cu.M |
| Warranty | 3 years or 3 00 000 km |
| Seating Capacity | D + 2 |
| DEF Tank Size | 18 L |
| FIP Model | Bosch CR System (2 000 + bar pressure) |
| Service Interval | 20 000 kms or 1 Year. Hub Greasing 1.2 Lakh kms, Gear Oil Change Interval - 2.4 Lakh kms |
Tata Motors Commercial Trucks
Tata Motors trucks connect India and power the engines of the nation’s growing economy. With multiple options for payload, drivetrains, and applications, Tata Motors offers a wide range of light, medium, and heavy trucks. Advanced technologies and a suite of value-add services ensure our trucks promote smart mobility and deliver progress with best-in-class operating economics.
